The wM-Bus Gateway receives wireless M-Bus protocols in T/C/S mode, filters them as needed, stores them temporarily, and sends them to a server via an IP connection.
The gateway does not have a mobile data connection. It only uses existing networks. The gateway is particularly suitable for stationary reception of wM-BUS protocols using an existing internet connection. Internet routers are usually already in place. In most cases, no changes need to be made to the router settings.
Simply plug the gateway into the router's USB port (optionally with a USB power supply) and connect it to the router with a network cable.
The gateway can optionally be parameterized via a website, USB interface or via the wM-BUS gateway server.
The received wM-BUS protocols can be pre-filtered in the device by manufacturer, medium code and/or by individual IDs.
The gateway sends the received and filtered data to the server either immediately, hourly, daily, or monthly.
The free "wM-BUS to TCP Gateway Server" can be used as the server, or an application developed by the user.
